| Technical Information - Catalogue |
 |
| Hydraulic Model-STD: FGN-2 3,0cv/1/164mm/3500rpm |
|
| SELECTED MODEL INFORMATION |
|
 Illustrative Photo
|
| Model-STD: FGN-2 3,0cv/1/164mm/3500rpm |
| Category: SUPERFICIE |
| Group: MONO ESTAGIO HORIZONTAL |
| Impeller Type: FECHADO |
| Power rating (hp) |
3,0 |
| Frequency (Hz) |
60 |
| Speed (rpm) |
3500 |
| Suction size |
1 1/2" / 2" |
| Discharge size |
1" / 2" |
| Impeller Diameter (mm) |
164 |
| Number of stages |
1 |
| Max free solids passage (mm) |
0 |
| Limits of operation (m³/h) |
3.93 a 12.23 |
| Limits of operation (mca) |
40.00 a 50.00 |
|
Pump Efficiency x Flow Rate
|
Performance referenced for: clean water, 20ºC, specific mass 1000Kg/m³ and viscosity 1,005mm²/s.
|
Sheet: 1/1
|
